5t/h Membrane Filtration System
I. Product Description:
This membraned filtration system is designed for high-precision liquid filtration in industries such as beer, rice wine, fruit juice, and beverages. Utilizing advanced polymer microporous membrane technology, it achieves progressive clarification and sterilization by intercepting impurities and bacteria while allowing target molecules to pass through.
The fully enclosed design eliminates contamination risks, reduces oxygen exposure (1/5 of traditional plate filters), and minimizes product loss. It supports CIP (Clean-in-Place) and hot water/alkali backflushing for efficient regeneration with low water consumption.
II. Peculiarity:
-Three-Stage Filtration: 1μm (pre-filtration) → 0.65μm (fine filtration) → 0.2μm (final sterilization).
-Hygienic Design: SS304 construction, tri-clamp connections, no dead corners.
-High-Temperature Resistance: Withstands 121℃ sterilization and 142℃ max temperature.
-Modular & Scalable: Flexible configuration for flow rates up to 5t/h.
III. Technical Parameters:
| Parameter | Primary Filter (Pre-Filtration) | Secondary Filter (Fine Filtration) | Tertiary Filter (Final Filtration) |
| Model | A | B | C |
| Flow Rate | 5 t/h | 3 t/h | 3 t/h |
| Filtration Rating | 1 μm | 0.65 μm | 0.2 μm |
| Cartridge Length | 30 inches | 30 inches | 30 inches |
| Cartridge Material | Polypropylene (PP) | Polypropylene (PP) | Polysulfone (PSU) |
| Cartridge Qty | 3 pcs | 3 pcs | 3 pcs |
| Operating Pressure | 0.4 MPa | 0.4 MPa | 0.4 MPa |
| Max. Temperature | 142℃ | 142℃ | 142℃ |
| Sterilization Temp | 121℃ | 121℃ | 121℃ |
| Housing Material | SS304 | SS304 | SS304 |
| Connection Size | Φ38 | Φ38 | Φ38 |
IV. Typical Applications：
-Beverages: Clarification and sterilization of beer, rice wine, fruit juice.
-Food Processing: Pre-filtration for aseptic filling.
-General Liquids: Removal of particles, colloids, and microorganisms.
V. Standard Components：
-SS304 filter housings with quick-open clamps
-Pressure gauges (0-1MPa) and vent valves
-CIP/backflush piping (Φ38)
-Adjustable stainless steel feet
