General Introduction of 500 - 800kg/hr Grain Miller
The 500 - 800kg/hr grain miller is a high-efficiency malt crushing machine specially designed for medium to large-scale craft breweries and commercial brewing operations. It is mainly used to crush malted barley, wheat, corn, rice, and other brewing grains before the mashing process, ensuring an ideal particle size distribution for maximum extraction and smooth lautering.
This model features precision-engineered rollers made from hardened steel or stainless steel, providing excellent durability and consistent crushing performance. The adjustable roller gap allows brewers to set the desired crush level for different recipes. Driven by a high-power, energy-efficient motor, the mill runs smoothly with low noise and minimal maintenance requirements.
With a processing capacity of 500 - 800 kg/hr, the mill offers strong throughput while maintaining uniform milling quality. It can be equipped with optional components such as a malt hopper with level sensor, dust-proof cover, auger conveyor, and base frame to create a fully integrated and clean milling system.
Technical Specifications of 500 - 800kg/hr Grain Miller
Contact Us
The 500 - 800kg/hr grain miller combines durability, high capacity, and precision control - making it an ideal solution for breweries that require efficient and consistent grain preparation to support continuous beer production. Kindly contact us to get your professional milling solution.
The 500 - 800kg/hr grain miller is a high-efficiency malt crushing machine specially designed for medium to large-scale craft breweries and commercial brewing operations. It is mainly used to crush malted barley, wheat, corn, rice, and other brewing grains before the mashing process, ensuring an ideal particle size distribution for maximum extraction and smooth lautering.
This model features precision-engineered rollers made from hardened steel or stainless steel, providing excellent durability and consistent crushing performance. The adjustable roller gap allows brewers to set the desired crush level for different recipes. Driven by a high-power, energy-efficient motor, the mill runs smoothly with low noise and minimal maintenance requirements.
With a processing capacity of 500 - 800 kg/hr, the mill offers strong throughput while maintaining uniform milling quality. It can be equipped with optional components such as a malt hopper with level sensor, dust-proof cover, auger conveyor, and base frame to create a fully integrated and clean milling system.
Technical Specifications of 500 - 800kg/hr Grain Miller
| Function | Malt crushing |
| Model | JMF-3A-30, OEM by Shuangjia |
| Ave. Capacity for Malt | 500-800kg/hr |
| Cover and Frame Material: | Stainless steel |
| Drive Power: | 3kw motor CE [UL available] |
| Design | Nylon and Chrome gear box for reducing running noise |
| Hopper | 80L malt hopper for at least 30kg malt |
| Roller Size | Φ155x200mm, double |
| Roller Distance | Rollers clearance adjustable for various malt particle |
| Roller material | Hardening chrome steel, washable |
| Roller Speed | Roller speed differencial for higher malt efficiency |
| Faster Roller Speed: | 700rpm |
| Magnet | Strong magnet to remove iron pieces |
| Ratio of Magnetic Metal Material | ≤0.003g/kg |
| Temperature of Rollers after Production | ≤56℃ |
| Optional | Bag collecting/Auger connection |
Contact Us
The 500 - 800kg/hr grain miller combines durability, high capacity, and precision control - making it an ideal solution for breweries that require efficient and consistent grain preparation to support continuous beer production. Kindly contact us to get your professional milling solution.
